GEPRC Tern-LR40 HD O3 Long Range FPV - TBS Nano RX
Summary
In the GEPRC family, we have welcomed a new member: Tern-LR40. This is a 4-inch long range FPV with excellent performance and reliability. It adopts a DC-type structure. Its careful lightweight design uses aviation-grade 7075 aluminum parts. Light and rigid.
Equipped with Taker G4 45A AIO flight control, which has higher computing power redundancy. The use of a top-mounted fixed GPS can avoid the impact of its own electromagnetic interference on flight, and the rescue function is more stable.Silicone camera shock-absorbing pad prevents high-frequency jello from O3 camera.
The Tern-LR40 is like a bird with spread wings, flying freely through the blue sky without being restrained. Choosing it is not only a high-quality flight, but also an artistic journey.
Feature
- New lightweight design, weight under 249g.
- Expand interference GPS fixation method and stay away from interference sources
- DC structure cannot see the propellers during flight, which is more suitable for straight-line aerial photography.
- Install BB ring to set the battery low voltage alarm
- Using GEP-M10nano GPS, the satellite search speed is faster and the rescue mode is more stable.
- Compatible gopro mount installation, expandable shooting creation.
Specifications
- Model: Tern-LR40
- Frame: Tern-LR40 Frame
- Wheelbase: 180mm
- Top plate: 1.5mm
- Mid plate: 2.0mm
- Bottom plate: 1.5mm
- Arm thickness: 3.5mm
- FC: Taker G4 45A AIO
- MCU: STM32G473CEU6
- Gyro: ICM 42688-P
- OSD: Betaflight OSD w/AT7456E
- ESC: 32Bit 45A
- VTX: O3 Air Unit
- Camera: O3 camera
- Antenna: 5.8G&2.4G
- Motors: GEP-SPEEDX2 1404 3000KV
- Connector：XT30
- Propellers: HQProp T4X2.5Grey (2CW+2CCW)
- Tern-LR40 O3 PNP version weight: 180g±5g
- Receiver: PNP/GEPRC ELRS24/GEPRC ELRS915/TBS Nano RX
- Recommended battery: LiPo 4S 660mah-850mah/18650 3000mah
- Flight time: 10-25min
Includes
1 x Tern-LR40
2 x HQProp T4X2.5Grey (2CW+2CCW)
2 x battery anti-slip mat
1 x screw pack
4 x Battery strap M15*170mm
1 x L-shaped screwdriver 1.5mm
1 x GoPro camera mount holder
1 x T-type Antenna mount
1 x RC Printed
